Thursday, November 7, 2019

How avoidance of detailed ground study resulted in failure of road infrastructures

As usual, I always begin by thinking, whenever I see failure in road infrastructures; road construction in Bhutan has already past half a century after its inception in early 1960s.  Exactly, at this time, mule tracks and footways are mere history to track back. Roads replaced all those detour tracks for transportation that touches high mountains and deep valleys. Slope failures on those tracks were out of question since these don’t have one except than the natural slope. But, the road construction comes with designs that require cut and fill that develops another slope in addition to natural slope, which is called cut and fill slope. The failure mechanism of these slopes must be addressed and learned. Despite engaging into road construction and maintenance for decades, are we enough with the trend? We have many questions to ask and things to do. Let the custodian of road don’t bounce from one agency to another.

Department of Roads, in the 11th fifth year plan and in the beginning of current plan, Geog Connectivity roads were with the department. Planning and budgeting works were mandate for the department. Finally, those roads were handed over to Local Government. Inconsistency in the decision of springing the custodian has left those improved roads further deteriorated and damaged.

We are adequate with road coverage. Every nook and corner of the country is connected. We are enough with the length. Length of roads has out numbered the technology involves. Now, what we need is advancement of technologies with the change.

Bailey Bridge subsided under the catastrophic slope failure.
Construction techniques of the road, starting from formation cutting to pavement strengthening have improved with advancement and introduction of new machineries and methods. Environment friendly road construction technique was started in the late years of 9th fifth year plan and now the time has triggered and reminded to start preparation to integrate the construction of climate resilient road infrastructures.

Indeed, monsoon has taught us good lessons. The change, we see through more destruction and damages in road infrastructures than before. We feel the change through roadblocks.

How it is possible to overcome the change, especially the climate change?  What are differences in failure we observe between then and now? Are those failures due to climate change or something else?

Pavement or the road fails because of failure of permanent structures – walls, drains, cross drainages and slope etc.  Bridges usually fails because of overloading and slope failure. Otherwise, bridge failure due to other reasons is least that we usually counteract immediately.

Let me explain one simple example- provision of both sides camber on pavement in any category of roads. Our Primary National Highways are wide enough to provide camber on both sides and so is likely with the Secondary National Highways. But, is it really possible on Dzongkhag and farm roads? And our standards say that the camber should be on both sides. The standard carriageway width is only 3.5 meters. From my personal experience, there is constructability issue. Even if there is no constructability issue like in aforementioned category of highways, providing camber on both sides is unnecessary considering the different nature of soil conditions on downhill slope. We must avoid infiltration of runoff from the pavement, prevent saturation of slope, and let fail the slope grossly.

And why our walls repeatedly fail on the same location?

Pavement failure due to excessive infiltration.
Likewise, are our standard design road drainages or cross drainages adequate? Or do we need to revise?

The evidence of aggravating damages year after year on road infrastructures and restoration works that cost us dearly, must be felt in every individual responsible and indeed must be felt on end user as well. Or else we wait for the catastrophe that is looming large before us.

Therefore, road infrastructures designed and constructed decades ago may not suffice the change now. We may need to revise the design criteria and focus more on slope stability study. Much more information and awareness on knowledge regarding slope engineering is indeed felt necessary on top of the training provided for construction quality in conjunction with more effective road asset management.

Thursday, September 5, 2019

Tunnel Roads – the next phase of transport system in Bhutan

Department of Roads as parent agency for highways in Bhutan under Ministry of Works and Human Settlement has galloped a long journey since the start of first highway construction in early 1960s. Beyond highways, in the 11th fifth year plan, department was ushered responsibilities for construction and maintenance of whooping networks of Geog Connectivity (GC) roads. At the inception of 12th fifth year plan and thus far, almost all surface roads construction and improvement were completed; overall the adequacy of road networks have been accomplished under the dynamic farsighted leadership of the department. After successful completion of blacktopping of 182 GC roads out of 205, those roads were handed over to Local Government (LG), leaving the department mandated to focus only on highways.

Nonetheless, journey of further enhancement and development of transportation system in the country must travel far to the world standards for enhancement of socio-economic development.

For that matter, as reflected in the current plan document, the next stage for the department to get engage is in tunneling and underground space engineering works. Best for the country like ours that is geologically challenging and mountainous, start of tunneling works shall gear the department in accomplishing the mission statement of reducing travel time.

The first ever underground/tunnel road (1.50 km) (Video published by Bhutan Tube)was constructed on Tsirang – Wangdue National Highway by Punatshangchu Hydro project II and successfully opened to traffic on 25th June 2014.

Since the start of hydro-power plants construction to meet the target to harness 20000 MW by 2020, Bhutanese in general have seen tunnel construction in hydro sector only.

Highway tunnel on Tsirang - Wangdue National Highway. Photo from PHPA-II website
Tunneling roads will not only help in reducing travel time, it will also reduce the current setback triggered by unusual monsoon. Though the initial construction expenditure will be huge as compared to surface roads, operation and maintenance costs will be minimum; thereby, the best judgment to invest in the tunneling works considering the Life Cycle Costing and also the climate change effect on the roads such as now will be meager.

For that matter, it is time for the government and department in particular to start groundwork for the tunneling and underground space engineering knowledge. Ultimately, with tunnel roads that are best suited for country like ours, transportation system will be in the next level.

Therefore, as an introductory process to tunneling, short course on tunneling is scheduled on 24th to 27th September at Druk Hotel, Thimphu. Dr. Manoj Verman, Tunneling and Rock Engineering Expert, President, Indian National Group of ISRM (International Society for Rock Mechanics and Rock Engineering) is organizing the course. The course fee is Nu. 17,000.00 (Seventeen thousand only).

I aspire, interested engineers of the nation would participate in the short course to originate light in future tunnel roads and underground space engineering.

post signature

Thursday, June 27, 2019

Blacktopping of Dakpai-Buli-Nimshong GC Road

Dakpai-Buli-Nimshong GC Road starts at Dakpai, 18.00 km on Tingtibi – Zhemgang SNH at an altitude of 1263 m. It traverses through forest touching many villages until Buli (36.60 km), 1698 m. The highest elevation, it passes between Dakpai & Buli is at Talila (18.00 km), 2014 m.

From Buli, the road inclines up through randomly dense forest till Gonglithang (5.10 km), 2154 m. The road further inclines up through the continuously dense forest & crosses Malaya top (10.50 km) at an altitude of 2626 m. The road, then declines down until Rongdigang (19.60 km), 1833 m and incline bit up with four short zigs. Further it traverses straight until Churmulung (25.50 km), 1937 m and then decline down till Nimshong (30.20 km), 1740 m.

The road, Dakpai-Buli was constructed in early years of ninth fifth year plan and Buli-Nimshong road was constructed in later years of 10th fifth year plan.

Blacktopping work in progress at Nimshong
From the above alignment description of the road, it is clear that the road stretch from Dakpai to Buli (36.60 km) passes through uniform elevation variation. Whereas, the road stretch from Buli crosses the highest elevation variation. Due to high elevation and dense forest cover along Gonglithang until Rongdigang, the road corridor and the pavement in particular receive less sun, leaving the road stretch marshy and damp throughout the year.

Although major sections of the road have been blacktopped, it is observed deterioration of wearing coarse in the form of potholes; alligator cracks, depression distress, shoving etc. At certain stretch, the gross failures of pavement are observed.

Due to more damp and marshy locations, almost 2.40 km of road beyond Malaya towards Nimshong were left without blacktopping.

Road stretch through dense jungle beyond Malaya
To forgo the blacktopping of marshy sections, discussion were held in various meetings and even in Department’s Quarterly meeting and resolute the same.

That’s why, certain stretch along Buli to Nimshong GC (2.40 km out of 30.20 km target) road was not blacktopped. Nonetheless, estimates for the remaining pavement improvement works have been prepared inclusive of cross drainage and road drainage for the betterment of smooth road along the high elevation ranges.

I generously regret the inconveniences caused to the public of Upper Kheng, UK.

post signature

Thursday, September 21, 2017

Life Cycle Cost Awareness in Bhutanese Construction Industry

A book published. Self authored. Go through the abstract. Thank you.

Significant knowledge gaps exist in the knowledge of Life Cycle Costing and the alternatives selection of building materials in the construction industry. In order to fulfill the gaps a questionnaire survey was developed for 319 respondents in using the Life Cycle Costing for the Bhutanese construction industry. Life Cycle Cost Analysis of selected components of the selected building was done taking into account relevant economic factors: initial costs, maintenance and operational costs.

The maintenance and operation costs are generally ignored in building industry especially in design stage. For this research, the method of LCC, present worth cost approach was evaluated with projection of building service life as 60 years, inflation rate as 9.07% and discount rate as 0%.

A book published by Lambert Academic Publishing

About 52% of the respondents do not have idea about LCC when making investment decisions nor do they not take maintenance, operation and replacement cost into consideration. The lack of significant input-cost data and lack of experience appears to be the most important problem supported by 78% responded lack of experience and 62% responded lack of significant input-cost data.

The LCC analysis showed that ceramic tiles, pre-painted CGI sheet and LED lamp has the lowest life cycle cost among the many material alternatives available in the market, that is, 16% for LED lamp, 13% for ceramic tiles and 64% for pre-painted CGI sheet.

Click the link to buy if anyone wish to use it for academic purpose or any related research reference.


post signature

Friday, January 13, 2017

Gold Mother

Mostly wander I swing deprived missing nearby eatable,
In the golden fur of beautiful raiment cover.

Jumping madly off the branches with mates
And peaceful rest to feed kiddo makes the wander wonder.

Golden Langur of Zhemgang

Profound dark face; golden raiment cover of gold & long extreme tail
You are named Golden Langur.

Languorous care for the little one on the creepy branches,
Lively lovely gold mother, I see in you as I stare.
I recede with smile...
